L.A. Baby West Coast Gate SG-35 - Manual (Page 3)

Never use without Mounting cups.
.
!
WARNING
Side view
Correct!
rubber pad
fasten mounting cups to the wall with screws or double-coated tapes
double-coated tapes
screws
3A 3B
Correct!
Top view
Correct!
3C 3D
-3-
Note: Do not use this gate if it can't be installed to walls, doorframes or posts tightly and flatly. If the gate is not installed vertically, the
automatic close feature will be hindered.
3.Place the gate in the opening so that the bottom of the gate frame is completely flat on the floor (3A). To secure the gate, fasten the
mounting cups to the wall on the vertical lines from the floor with the screws or double coated tape that have been provided, so that
the mounting cups at the top are directly above those at the bottom (3B) (3C) (3D).
2C
Gate Frame Extension Frame
Tension Knob
long end
Bolt
the long ends of the Extension Frame
Extension Pin
Extension Pin
Long end insert into the Gate Frame
Extension Frame
2A 2B
!
WARNING
Do not install extension frames unevenly on either side of the gate
– if using2 extensions install 1 on each side , if using 3 install 1 on one side
and 2 on the other , if using 4 extensions install 2 on each side
( see page 2 drawings 1C,1D,and 1 E)
