KV2 Audio ESD1.18 - Manual (Page 8)

ESD1.15 Specifications:
Specifications
ESD1.15
Specifications
8
System Acoustic Perfomance
Max SPL Long-term 127dB
Max SPL Peak 130dB
-3dB Response 37Hz ÷ 150Hz
Recommended Power 600W
Sensitivity 99dB (half-space area)
Impedance 4Ω
Crossover Point 80Hz ÷ 150Hz
Low Frequency Section
Acoustic Design Twin Asymmetrical loading
Number of Drivers 1
Woofer Size / Voice Coil Diameter / Design 15" / 3" / Inside Outside
Diaphragm Material Epoxy Reinforced Cellulose
Magnet Type Neodymium
Protection Thermal breaker - autoreset
Speaker Input
Speaker Input 2x Neutrik Speakon®, Terminal Block
Cabinet
Cabinet Material Baltic birch
Handles 2
Pole Mount M20
Flyware 8x M10 suspension points
Color "Orange peeled" Matt Black or any
RAL
Physical Dimensions
Height 510mm (20.08")
Width 550mm (21.65")
Depth 570mm (22.44")
Weight 31kg (68.34lbs)
