KV2 Audio ESD1.18 - Manual (Page 11)

ESD1.18 Specifications:
Specifications
ESD1.18
Specifications
11
System Acoustic Perfomance
Max SPL Long-term 131dB
Max SPL Peak 134dB
-3dB Response 30Hz ÷ 150Hz
Recommended Power 1000W
Sensitivity 100dB
Impedance 8Ω
Crossover Point 80Hz ÷ 150Hz
Low Frequency Section
Acoustic Design Twin Asymmetrical loading
Number of Drivers 1
Woofer Size / Voice Coil Diameter / Design 18" / 4" / Inside outside
Magnet Type Neodymium
Diaphragm Material Epoxy Reinforced Cellulose
Protection Thermal breaker - autoreset
Speaker Input
Speaker Input 2x Neutrik Speakon®, Terminal Block
Cabinet
Cabinet Material Baltic birch
Handles 2
Pole Mount M20
Flyware 8x M10 suspension points
Color "Orange peeled" Matt Black or any RAL
Physical Dimensions
Height 612mm (24.1")
Width 700mm (27.56")
Depth 750mm (29.5")
Weight 52kg (114.7lbs)
