KV2 Audio ESD1.18 - Manual (Page 5)

ESD1.12 Specifications:
Specifications
System Acoustic Perfomance
Max SPL Long-term 124dB
Max SPL Peak 127dB
-3dB Response 38Hz ÷ 150Hz
Recommended Power 600W
Sensitivity 97dB
Impedance 4Ω
Crossover Point 80Hz ÷ 150Hz
Low Frequency Section
Acoustic Design Twin Asymmetrical loading
Number of Drivers 1
Woofer Size / Voice Coil Diameter / Design 12" / 3" / Inside outside
Magnet Type Neodymium
Diaphragm Material Epoxy Reinforced Cellulose
Protection Thermal breaker - autoreset
Speaker Input
Speaker Input 2x Neutrik Speakon®, Terminal Block
Cabinet
Cabinet Material Baltic birch
Handles 2
Pole Mount M20
Flyware 8x M10 suspension points
Color "Orange peeled" Matt Black or any RAL
Physical Dimensions
Height 370mm (14.57")
Width 800mm (31.49")
Depth 400mm (15.75")
Weight 28kg (61.7lbs)
ESD1.12
Specifications
5
