STEP 6
STEP 7
H
U
R
W
U
O
3 3
4 4
//
C
P
C
C
#2=
At each end of CROSS BAR
start BOLTS & WASHERS
Slide BOLTS & WASHERS into SLOTTED BRACKETS
on the INSIDE
CLAMP PLATES , snug with an open end 3/4" wrench (included in this package)
H O
(MOUNTING PLATES WILL VARY)
Depending on the make and
model of truck.
7a
P
KS _11_1.1
P
O
H
01
The front Mounting Plates have Support Arms. Slide one Arm
into the other and attach this assembly loosely to the front
legs of the rack using bolts P, lock washers O , and flat
washers H. Attach rear Mounting Plates loosely to legs using
bolts P, lock washers O & flat washers H.
