2.4. Technical specifications
Heating Immersion Circulator MB
Working temperature range °C 20 ... 100
Temperature stability °C ±0,02
Overall dimensions (WxDxH) cm 13x15x33
Usable bath depth cm 8 ... 14,5
Weight kg 4,0
Mains power connection 230 V/50 Hz V/ Hz 190-253 / 50
Current draw (at 230 V) A 9
Mains power connection 230 V/60 Hz V/ Hz 190-253 / 60
Current draw (at 208 V / 230 V) A 8 / 9
Mains power connection 115 V/60 Hz V/ Hz 103-127 / 60
Current draw (at 115 V) A 9
Mains power connection 100 V/50-60 Hz V/ Hz 90-110 / 50-60
Current draw (at 100 V) A 9
MB
Temperature selection digital
via keypad indication on MULTI-DISPLAY(LED)
remote control via personal computer indication on monitor
Temperature indication MULTI-DISPLAY (LED)
Resolution °C 0.01
Absolute Temperature Calibration °C ±3
Temperature control PID 2
Heater wattage (at 230 V) kW 2,0
Heater wattage (at 115V) kW 1,0
Circulating pump:
discharge, max.at 0 bar l/min 10
pressure, max. at 0 l bar 0.12
Electrical connections:
External alarm device Vdc/mA 24-0 / max. 25
Computer interface RS232
Ambient temperature °C 5 ... 40
All measurements have been carried out at: rated voltage and frequency
operating temperature: 70 °C ambient temperature: 20 °C bath fluid: water
Technical changes without prior notification reserved.
