I.R.I.S. 507 User Manual
Page 5
M5 Fixing Holes
(4 Positions)
Ø65mm
100mm
10
0m
m
80mm Pitch
80
m
m
Pi
tc
h
IRIS506/507/517 Joystick Fixing Template
