Routing Commands
RS232 Commands
RS232 Settings: 19200 baud, 8 Data bits, 1 Stop bit, Parity = None
x = Input Number (input 2 would be 2)
y = Output Letter (output C would be C and must be in caps)
= Carriage return (Hex 0D)
= Space (Hex 20)
A carriage return is required at the end of all command strings. Any changes made to the matrix via front panel,
IR, or web browser will be replied on the RS232 port.
Control via IP is not available on the DL-HDM44�
Description Command Response
Route input x to output y yx yx
Route input x to all outputs ABCDx ABCDx
Route input x to multiple outputs y
Number of outputs is unlimited
yyx yyx
Reset AV routes to A1, B2, C3, D4 RS RS
ABCD2 Route Video and Audio from input 2 to all outputs
C4 Route Video and Audio from input 4 to output C
BD3 Route Video and Audio from input 3 to outputs B and D
Examples:
System Commands
Description Command Response
Power full ON P1 P1
Power off (Standby Mode) P0 P0
Get firmware version and matrix state ST ST
DL-HDM44
F/W Ver : v1.0E
Power : On
EDID : STD
Port : A1B2C3D4
Display all RS232 commands ? Outputs list of all commands
