Specifications
Source Impedance Requirements Video OUT: 75 ohms
Audio OUT: 600 ohms max.
Destination Impedance
Requirements Video IN: 75 ohms
Audio IN: 600 ohms min.
Hub Impedance Video IN: 100 ohm balanced
Audio IN: 10 kohms min. balanced
Video OUT: 100 ohms balanced
Audio OUT: 600 ohm balanced
3 dB Bandwidth Video: DC to 8 MHz.
Audio:50 Hz to 16 kHz
Maximum Differential Input Video: 0.55 Vp-p Audio: 0.50 Vp-p
Maximum Differential Output Video: 0.55 Vp-p Audio: 0.50 Vp-p
Insertion Loss (differential) Video: 0 dB max. @ 4 MHz
Audio: 1 dB max. @ 1 kHz
Video Return Loss
24 dB minimum
Common Mode Rejection
Input: balanced
Output: unbalanced Video: Greater than 40 dB over the frequency range.
Audio: Greater than 60 dB over the frequency range.
Crosstalk Immunity 60 dB minimum over the frequency range
Max. Distance via
Cat 5 Twisted Pair (UTP) * Composite Video Color: 2200 ft (670m) *
Composite Video B&W: 2500 ft (762m) *
S-Video: 1000 ft (305m) *
*Measured between Source (ie;DVD) and Destination (ie;Monitor) with Hub placed
anywhere between the source and destination
Cable – UTP
24 gauge or lower solid copper twisted pair wire impedance: 100 ohms at 1 MHz.
Cat 3 or better.
Connectors Source Input: (1) RJ45 jack on rear panel
Looping Output: (1) RJ45 jack on rear panel
Distribution Outputs: (8) RJ45 jacks on front panel
RJ45 Pin Configuration
Reverse Polarity Sensitive Video 1: Ring 7 Tip 8
Audio 1: Ring 1 Tip 2
Video 2: Ring 4 Tip 5
Audio 2: Ring 3 Tip 6
Diagnostics Power LED – Green
Power Supply External AC: 110V and 220/240V
DC: +/- 12VDC, 5W total max.
Power Supply Connector 5-pin DIN; pin 1 GND, pin 2 GND, pin 4 -12V, pin 5 +12V.
Temperature Operating: 0 to 55 C. Storage:-20 to 85 C. Humidity: up to 95% non-condensing
Dimensions 8.5” x 4” x 1.3”
Compliance FCC, CE-EMC Directive 89/336/EEC
