HYDAC FPS Series - Manual (Page 2)

2 Charging & Gauging Units
PN#02068202
• ACU1107-1367 / 09.11
ACCUMULATORS
FPS
Version 4
FPK
Version 1
valve
protection
cap
(where applicable)
Valve
seal cap
O-ring
Allen Wrench 6 mm
(to be used to crack open M8 SHCS.
T handle on FPK Charging is not robust
enough to overcome recommended torque)
Valve protection cap
(where applicable)
O-ring (where applicable)
Socket Head
Cap Screw (M8)
Seal ring
T-Handle T-Handle
Check
Valve
Cap Nut Cap Nut
Manual
Bleed
Valve
Manual
Bleed
Valve
Figure 1
Figure 2
