8 9
Note: The lower settings may not be visible
during bright daylight.
The batteries are CR2032 coin style lithium batteries.
To insert a battery unscrew the battery compartment
cap on the top of the rheostat adjustment turret and
insert a new battery “+” side up.
Note: Always hold onto the lower half of the rheostat
when loosening or tightening the cap to ensure no
damage is done.
reticle overvieW
Detailed reticle information is available on the free
Hawke Ballistic Reticle Calculator software. Available
for PC, MAC, iPhone and android. For more
information visit www.hawkeoptics.com.
AMx
The AMX reticle is true at 10x and features infinitely
adjustable red illumination that is suited for target
gB
2. Locate the side wheel and place into the
grooves on the side focus shaft. The wheel is
designed to fit one way only into the grooves. This
ensures its position is correct in relation to the
markings on the side focus shaft.
3. When the side wheel is in place, replace the nut and
tighten using the key.
illuMinAtion
The illumination rheostat is located on the side of the
saddle or on the eyebell (side focus riflescopes)
The illumination rheostat has two positions, off and
on/variable. The brightness is stepless and infinitely
adjustable. High brightness settings are
recommended for daytime use when ambient
light is bright, this will allow the reticle to be visible
against dark backgrounds. At times of low light
such a dawn or dusk, lower brightness is recommended.
