25
ELEVATION - MODEL 418P COMPLETE TRACK
PLAN VIEW - MODEL 418P COMPLETE TRACK
424 8" BLACK
SINGLE
END PULLEY
423 8" BLACK
DOUBLE
END PULLEY
418P TRACK
TRACKS AT CENTER
OVERLAP
#410 TRACK
418 BLACK SINGLE CARRIER AND 419 BLACK MASTER CARRIER
NOTE: 416P dimensions similar.
&
2-3/4"
2-5/8"
3"
6-1/8"
409 END STOP
& CORD
SUPPORT
419 BLACK MASTER CARRIER
405 OVERLAP CLAMP
424 8" BLACK
SINGLE END PULLEY
418 BLACK SINGLE CARRIER
406 CLAMP HANGER
412A REAR
FOLD GUIDE
420 OPERATING LINE
422 BLACK ADJUSTABLE FLOOR BLOCK
423 8" BLACK
DOUBLE END PULLEY
2'-0" OVERLAP
5/8"Ø
412A REAR
FOLD GUIDE
431A
RUBBER
BUMPER
420
OPERATING LINE
2-1/4"
4-1/4"
1-13/16"
2"
3/8"
1/2"
7-1/4"
2-3/16"
2-3/4"
5-5/8"
10"
10-9/16" 8-5/16" 8-1/2" 6-1/8"
3"
10"
4-15/16"
