Page 4
Compliance:
See ICC-ES Evaluation Report ESR-2185
Florida Building Code Approval - FL6645
Warnock Hersey Certification Listing - ASTM D 226, ASTM E 108, ICC-ES AC188, TAS-104
For the most current product and code compliance information go to www.green-guard.com
8. Installation – Roof-Wall Intersections
A.
The roof underlayment is installed prior to the step flashing as shown below.
Figure 7: Installation - Step Flashing and Kick-Outs
Figure 6: Installation - Roof Ridge and Roof/Wall
1-800-241-4402 www.green-guard.com
GreenGuard
®
Synthetic Roofing Underlayment Installation Guide
GreenGuard
®
is a registered trademark of Pactiv LLC.
©2013 Pactiv LLC.
4/13
INSTL-SYNROOF
