B U I L D I N G W R A P A N D F L A S H I N G I N S T A L L A T I O N
4.0 FASTENERS AND FASTENING OPTIONS
GreenGuard® Building Wraps are mechanically attached either through structural sheathing
board or insulation board to underlying vertical framing members or directly to framing
members. For installation of GreenGuard® Building Wraps in residential or light commercial
building applications involving installation on structures that are less than 40 feet (5
stories) in height, refer to the GreenGuard® "Residential and Light Commercial Installation
Guide for GreenGuard® Building Wraps".
The following chart shows the fastening information for various framing and wall types:
Note: When attaching wall ties for anchoring masonry exterior claddings, first install a patch
of GreenGuard® Flashing at the penetration site before installing the wall tie. The patch
should be of a size adequate to seal only the penetration points.
5.0 FLASHINGS AND JOINT/SEAM SEALING
PRODUCTS
GreenGuard® Butyl Flashing Products
GreenGuard® Butyl Flashings are self-adhering membranes that have a butyl rubber
adhesive. These products are designed for use in sealing around window and door
openings, roof/wall intersections, deck/porch attachments to walls, pipe penetrations and
other areas that require a waterproof seal. GreenGuard® Butyl Flashings are designed
for sealing straight openings, while GreenGuard® SuperStretch™ Flashing is designed for
sealing around curved openings.
GreenGuard® Seam Tape (Custom)
GreenGuard
®
Custom Seam Tape is an adhesive tape that is used to seal building wrap
seams, repairs and around various types of wall penetrations that do not require a self-
adhering flashing membrane.
GreenGuard
®
C2000 Building Wrap
GreenGuard
®
MAX™ Building Wrap
GreenGuard® RainDrop
®
3D Building Wrap
Min. Required
Metal
Wood
Masonry
Metal
Wood
Masonry
Metal
Wood
Masonry
Screw Type:
Corrosion-resistant
(Example: galvanized)
1
5/8
in.
1
5/8
in.
1
5/8
in.
Tap Con
1
1
/
4
in.
1
1
/
4
in.
1
1
/
4
in.
Tap Con
1
1
/
4
in.
1
1
/
4
in.
1
1
/
4
in.
Tap Con
GreenGuard Caps Or
Metal/Plastic Washers,
(Min. diameter)
1
3
/
4
in.
1
3
/
4
in.
1
3
/
4
in.
1
3
/
4
in.
1
3
/
4
in.
1
3
/
4
in.
1
3
/
4
in.
1
3
/
4
in.
1
3
/
4
in.
Fastener Spacing
(Max. spacing)
