Grayhill Racks 8 Channel - Manual

Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
System 50
System 50
0 1 2 3 4 5 6 7
Y B W R
AC INPUT AC OUTPUT DC INPUT DC OUTPUT
16 2 3 4 5 6 7 8 9 10 11 12 13 14 15
+
++
11
25/49
1
-+
3.00
(76,2) 3.50
(88,9)
0.25 (6,4)
0.25 (6,4)
0.40 (10,2)
7.50 (190,5)
8.00 (203,2)
TERMINAL STRIP FOR
FIELD WIRING
2.20 (55,9)
MAX.
1.40
(35,6)
0.45
(11,4)
2.60
(66,0)
0.30
(7,6)
KEY
SLOT
PINS
5/7
TERMINAL STRIP
FOR LOGIC SUPPLY
STANDOFF I.D.
0.15 (3,8) DIA.
(4 PLACES)
CLEARANCE
FOR #6 SCREW
0.75
(19,1)
USER INSTALLABLE JUMPERS
FOR +VCC (3 PLACES)
CARD EDGE OR HEADER
CONNECTOR FOR LOGIC
SIGNALS. (SEE NOTES)
PIN 1
NOTE: MAXIMUM TERMINAL
SCREW TORQUE NOT TO
EXCEED 5 IN-LBS.
8 CHANNEL RACK: Standard
Part No. 70RCK8
Dimensions are shown in inches
(and millimeters).
All tolerances are ± 0.010 (0,25)
unless otherwise specified.
RACKS
8 Channel
FEATURES
• For use with System 50 Style Controllers
• Available for Standard Miniature and
OpenLine ® Modules
• Panel and DIN Rail Mount Versions
• UL, CSA
Certified
System 50
6
