I/O Modules
Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
DC Output Modules
Available from your local Grayhill Distributor.
For prices and discounts, contact a local Sales
Office, an authorized local Distributor or Grayhill.
Miniature, Normally Open
70M-ODC5 70M-ODC5A
70M-ODC5B
70M-ODC15
70M-ODC15B
70M-ODC24 70M-ODC24B
Standard, Normally Open
70-ODC5
70-ODC5A
70-ODC5B
70-ODC15
70-ODC15B
70-ODC24
70-ODC24B
Specifications
Units
Maximum Line Voltage
Vdc
60
200
60
60
60
60
60
Load Voltage Range
Vdc
3-60
4-200
3-60
3-60
3-60
3-60
3-60
Max. Off-State Leakage @ Max. Line
mA
1.5
0.01
0.01
1.5
0.01
1.5
0.01
Maximum Turn-On Time
µSec
20
75
75
20
75
20
75
Maximum Turn-Off Time
µSec
50
750
500
50
500
50
500
Typ. Power Dissipation
W/A
1
1.5
1
1
1
1
1
Clamping Voltage
Vdc
80
360
80
80
80
80
80
Nominal Logic Voltage (Vcc)
Vdc
5
5
5
15
15
24
24
Logic Voltage Range
Vdc
2.5-10
2.5-9
2.5-10
10-18
10-18
15-30
15-30
Maximum Logic Supply Current
@ Nominal Vcc
mA
14
18
14
9
9
9
9
Nominal Input Resistance (Rx)
Ω
300
220
300
1800
1800
2700
2700
Minimum Drop Out Voltage
Vdc
1
1
1
1
1
1
1
Type/Function
Grayhill Part Number
Standard and Miniature Modules
SPECIFICATIONS: By Part Number
G5 and OpenLine
®
Modules
70G-ODC5
70G-ODC5
70G-ODC5
70G-ODC5
70G-ODC5
70G-ODC5A
70G-ODC5A
70G-ODC5A
70G-ODC5A
70G-ODC5A
70G-ODC5B
70G-ODC5B
70G-ODC5B
70G-ODC5B
70G-ODC5B
70G-ODC15
70G-ODC15
70G-ODC15
70G-ODC15
70G-ODC15
70G-ODC15B
70G-ODC15B
70G-ODC15B
70G-ODC15B
70G-ODC15B
70G-ODC24
70G-ODC24
70G-ODC24
70G-ODC24
70G-ODC24
70G-ODC24B
70G-ODC24B
70G-ODC24B
70G-ODC24B
70G-ODC24B
Maximum Line Voltage
Vdc
60
200
60
60
60
60
60
Load Voltage Range
Vdc
3-60
4-200
3-60
3-60
3-60
3-60
3-60
Max. Off-State Leakage @ Max. Line
mA
1.5
0.01
0.01
1.5
0.01
1.5
0.01
Maximum Turn-On Time
µSec
20
75
75
20
75
20
75
Maximum Turn-Off Time
µSec
50
750
500
50
500
50
500
Typ. Power Dissipation
W/A
1
1.5
1
1
1
1
1
Clamping Voltage
Vdc
80
360
80
80
80
80
80
Nominal Logic Voltage (Vcc)
Vdc
5
5
5
15
15
24
24
Logic Voltage Range
Vdc
4-6
4-6
4-6
10-20
10-20
18-32
18-32
Maximum Logic Supply Current
@ Nominal Vcc
mA
13
13
13
9
9
9
9
Nominal Input Resistance (Rx)
Ω
150
150
150
1500
1500
2700
2700
Minimum Drop Out Voltage
Vdc
1
1
1
1
1
1
1
Grayhill Part Number
Type/Function
Fusible, Normally Open
Specifications
Units
OpenLine
®
Modules
Type/Function
Grayhill Part Number
Dual, Fusible, Normally Open
70L-ODC
70L-ODCA
70L-ODCB
Specifications
Units
Maximum Line Voltage
Vdc
60
200
60
Load Voltage Range
Vdc
3-60
4-200
3-60
Max. Off-State Leakage @ Max. Line
mA
1.5
.01
.01
Maximum Turn-On Time
µSec
20
75
75
Maximum Turn-Off Time
µSec
50
750
500
Typ. Power Dissipation
WA
1
1.5
1
Clamping Voltage
Vdc
80
360
80
Nominal Logic Voltage (Vcc)
Vdc
5
5
5
Logic Voltage Range
Vdc
4.5-28
4.5-28
4.5-28
Maximum Logic Supply Current
@ Nominal Vcc
mA
7/CH
7/CH
7/CH
Module ID Resistance to Logic
Ground
Ω
2.15K
2.15K
2.15K
Minimum Drop Out Voltage
Vdc
1
1
1
I/O
