Custom options available
Contact Grayhill or your local
Grayhill sales representative
for more information.
ENVIRONMENTAL SPECIFICATIONS
Operating temperature ANSI/ASAE EP455 5.1.1
Level 2
-40°C for 4 hours to
+85°C for 11 hours
Storage Temperature ANSI/ASAE EP455 5.1.2
Level 2
-40°C 4 hours to
+85°C 4 hours
Thermal Shock ANSI/ASAE EP455 5.1.3 -40°C to 70°C at a rate of 4°C/
min (1 hour at extremes)
Altitude (Barometric Pressure) ANSI/ASAE EP455 5.2 101.3kPa to 18.6kPa
Sand and Dust ANSI/ASAE EP455 5.3 24 hours with 0.88g/m3
Solar Radiation ANSI/ASAE EP455 5.4 43 to 75W/m2 UV Radiation
(280 to 400nm wavelength)
for 300h
Wash Down ANSI/ASAE EP455 5.6 Level 2 375 kPa and 8.3 L/min for 10
minutes @15°C Water temp
Ingress Protection IP67 1 meter submersion for 30
minutes
Humidity ANSI/ASAE EP455 5.13 96% Humidity at 35°C for 240
hours.
Salt Fog ANSI/ASAE EP455 5.9 5% aqueous solution of NaCl
@ 35°C and a pH between 6.5
and 7.2 for 48 hours
Chemical resistance (Resis-
tance to Solvents)
ISO 16750-5 EP 455 (5.8.2)
Thermal Cycling (Change of
Temperature)
ISO 16750-4 -40° to 85°C 2 hours at
extremes change rate = 1°C/
min (8 hours) repeat for 30
cycles.
MECHANICAL PERFORMANCE
Vibration, Random ANSI/ASAE EP455 5.15.1 2 hours each axis @ 52.4 m/s2
RMS overall acceleration and
spectral power density of 2m2/s3
from 50Hz to 2000Hz
Vibration, Sinusoidal ANSI/ASAE EP455 5.15.2 A logarithmic sweep from 10Hz to
2000Hz to 10Hz over a period of
20 minutes for 4 hours in each of
3 orthogonal axes with amplitude
of 1.5mm from 10Hz to 40Hz and
a constant acceleration of 35m/s2
RMS from 40Hz to 2000Hz.
Shock / Crash Safety ANSI/ASAE EP455 5.14 A single 11ms half sine pulse of
490 m/s2 in 3 perpendicular axes.
Drop ANSI/ASAE EP455 5.14.2
Level 1
Drop component 400 mm onto a
hardwood benchtop on all
practical edges.
Shipping integrity International Safe Transit
Agency procedure 3A
ELECTROMAGNETIC COMPATIBILITY SPECIFICATIONS
ESD ANSI/ASAE EP455 5.12 +/- 25kV for 10 pulses, 5 of
each polarity
Radiated Immunity ISO14982 6.6 10MHz-1000MHz Range 48mA
Bulk Current Injection 100V/m
Conducted Emissions SAE J1113-41 Class 3
Broadband Radiated Emissions ISO14982 6.4 64dB to 54dB, 30MHz-75MHz
(linearly decreases) 54dB to
65dB, 75MHz-400MHz (linearly
increases) 65dB, 400MHz-
1000MHz
ELECTRICAL PERFORMANCE SPECIFICATIONS
Maximum load ANSI/ASAE EP455 5.1.1
Level 2
-40°C 4 hours +85°C for 11 hours
max load applied
Jump start forward voltage ISO 16750-2 36V for 60 minutes
Jump start reverse voltage ISO 16750-2 -36V for 60 minutes
Short circuit protection ISO 16750-2 All outputs to ground for 60s
Reverse polarity protection ISO 16750-2 28V for 60s
Starting profile ISO 16750-2 Class A
Battery-less operation ANSI/ASAE EP455 5.11.3
Level 2
Apply 6+12.6sin(2*pi*f*t) f is
swept from 500Hz to 1.5kHz 5min
Load dump ISO 7637-2 Test Pulse 5b Class A
Switching spikes – negative ISO 7637-2 Test Pulse 3a Class A
Switching spikes – positive ISO 7637-2 Test Pulse 3b Class A
Wire harness inductance ISO 7637-2 Test Pulse 2a
and 2b
Class A
+/- inductive load pulse ANSI/ASAE EP455 5.11.4 14-300e^(-t/.001)V 1Hz for 300
cycles
+/- mutual coupling ANSI/ASAE EP455 5.11.6
Level 2
14+200e^(-t/14x10^-6)V 1Hz for
300 cycles
Alternator field decay ANSI/ASAE EP455 5.11.2 Class A
CE COMPLIANCE
Agriculture and Forestry
Machinery EMC
ISO 14982 ESA
Construction Machinery EMC EN 13309:2000 ESA
Bulletin 1124
Rev 06/14
Pin 1 2 3 4
Signal Power Gnd CAN_H CAN_L
CONNECTION
4 pin Deutsch DT
Connector. Power
with 8V to 32V
vehicle type inputs.
ORDERING INFORMATION
Grayhill, Inc.
561 Hillgrove Avenue phone: (708) 354-1040
LaGrange, Illinois 60525 fax: (708) 354-2820
3 J X X X 5 - 2 0 0 N
Series Code
Keypad Symbols
0 = Blank
1 = ISO Symbols (as shown in dimensional drawing)
2 = Targets
Input Type
0 = Encoder
1 = Joystick Encoder
Protocol
Blank = J1939
N = CANopen
Custom Designation
200 = Default
Center Pushbutton
0 = No pushbutton
1 = Pushbutton (joystick always has pushbutton)
Configuration
5 = Default
MOUNTING INFO
Use M6 Nut (1mm pitch)
Max Torque 25 in-lbs
