Standard Keypads

Keyboards and Keypads

DimenSionS

in inches (and millimeters)

SerieS 88

Sealed, Flange mounted

3x4 Keyboard

termination

in inches (and millimeters)

3x4

Code and truth table

Dots in the chart indicate connected terminals
when switch is closed. Terminals are identified on
the keyboard.

3.000
± .015

(76,2

± 0,38)

2.800
± .010

(71,12
± 0,25)

.200 ± .010
(5,08 ± 0,25)

A B C F G H L M N

2.200 ± .015

(55,88 ± 0,38)

2.000 ± .010

(50,8 ± 0,25)

.100 (2,54)

TYP.

RETAINING
STUDS

.220 ± .010
(5,59 ± 25,4)

.100 ± .010
(2,54 ± 0,25)

BUTTON NO. 1
.093 ± .005
(2,36 ± 0,13)
DIA. 4 PLS.

C

L OF 2.200 (55,88) DIM.

1
2
3
4
5
6
7
8
9

10
11
12

CoDeS

3x4

matrix

Single Pole/Common Bus

terminal loCation

Button loCation

F E D K J H G

J E A K F B L G C M H D N

.500 .010
(12,7 ± 0,25)
(3 EQ. SPS)
TOL. NON-
ACCUM.

.380 (9,65)
SQ. TYP.

.750 ± .010

(19,05 ± 0,25)

COL

1

COL

2

COL

3

1.990 + .000 - .010

(50,55 + .000 - 0,25)

.055 ± .010
(1,40 ± 0,25)

.105 ± .010
(2,67 ± 0,25)

ROW 1

ROW 2

ROW 3

ROW 4

2.690 + .000/

- .010

(68,33 + .000/

- 0,25)

SWITCH KEY
IDENTIFICATION
(FOR REF. ONLY)

.500 ± .010 (12,7 ± 0,25)
(2 EQ. SPS.) TOL. NON-
ACCUM.

.600 ± .010
(15,24 ± 0,25)

.128 ± .010
(3,25 ± 0,25)

.280 ± .010
(7,11 ± 0,25)

.025 ± .002
(0,64 ± 0,05)
SQUARE
TERMINAL

.360 ± .010
(9,14 ± 0,25)

.072
± .010
(1,83
± 0,25)

COL = COLUMN

BUTTON AREAS ARE EMBOSSED

1 2 3

4 5 6
7 8 9

10 11 12

.150 ± .005
(3,81 ± 0,13) R.

FeatureS
• Sealed Keyboard
• Colorful Graphic Overlay
• Audible, Snap-Dome Contact
• User Legendable Styles
• 3,000,000 Operations per Button
• Optional Panel Seal Gasket to

Protect Your Equipment

MATRIX TERMINAL PIN-OUT

D E F G H J K

.100

TYP.

.600

SINGLE POLE COMMON BUS TERMINAL

A B C D E F G H J K L M N

.100
TYP.

1.200
