Standard Keypads
Keyboards and Keypads
SerieS 96
Conductive rubber
FeatureS
• Quality, Economical Keyboards
• Easily Customized Legends
• Matrix Circuitry
• Backlit and Shielded Options
Available
• Termination Mates With Standard
Connectors
• Tactile Feedback to Operator
• 1,000,000 Operations per Button
• Compatible With High Resistance
Logic Inputs
The Series 96 is Grayhill's most economical
3x4 and 4x4 keypad family. The contact system
utilizes conductive rubber to mate the appropriate
PC board traces. Offered in matrix circuitry, with
shielded and backlit options. Built with quality
component parts, the Series 96 is subjected to
our rigid statistical process control to insure that
it meets our reliability standards.
DimenSionS
in inches (and millimeters)
3x4 Front mount Keyboard
Standard Versions
Shielded/Backlit Versions
1
4
7
10
2
5
8
11
3
6
9
12
2.000 ± .015
(50,8 ± 0,38)
.500
(12,7)
1.000
(25,4)
.500
(12,7)
.500
(12,7)
1.000
(25,4)
1.500
(38,1)
.600
(15,24)
2.700
± .015
(68,58
± 0,38)
.150 (3,81) R.
4 CORNERS
.308 (7,82) SQ.
BUTTON 12 PLS.
SWITCH POSITION
IDENTIFICATION
.075 (1,91)
BUTTON
HEIGHT
.020 (0,51)
HIGH
BUTTON
GUARD
.250 (6,35)
4 PLS.
.200 (5,08)
GRAYHILL INC
.100 (2,54)
DIA. 4 PLS.
LABEL
1.700
(43,18)
.150
(3,81)
2.400
(60,96)
.150
(3,81)
.600 (15,24)
.550
(13,97)
.030
(0,76)
.340 ± .015
(8,64 ± 0,38)
.025 ± .002
(0,64 ± 0,05) SQ. PIN
.098 (2,49)
REF. TERMINAL
PIN HEADER
.100 (2,54) REF.
TERMINAL
PIN HEADER
7 6 5 4 3 2 1
TERMINAL PIN
IDENTIFICATION
.100 (2,54) TYP.
GRAYHILL INC
.100 (2,54)
DIA. 4 PLS.
LABEL
1.700
(43,18)
.150
(3,81)
2.400
(60,96)
.150
(3,81)
1.100 (27,94)
.350
(8,89)
.030
(0,76)
.340 ± .015
(8,64 ± 0,38)
.025 ± .002
(0,64 ± 0,05) SQ. PIN
1.700
(43,18)
2.400
(60,96)
.062 (1,57) R.
2 PLS.
.125
(3,18)
.125 (3,18) DIA.
2 PLS.
.125 (3,18) MAXIMUM
PANEL THICKNESS
RECOMMENDED
10 9 8 7 6 5 4 3 2 1
.098 (2,49)
REF. TERMINAL
PIN HEADER
.100 (2,54) REF.
TERMINAL
PIN HEADER
1 0 9 8 7 6 5 4 3 2 1
TERMINAL PIN
IDENTIFICATION
.100 (2,54) TYP.
FRONT
PANEL
MOUNT
CUTOUT
