Standard Keypads
Keyboards and Keypads
type no. Sample Style Sub Surface top Surface
and typical and typical Character and Character and
height Sizes line limitations line limitations
4gh088
.083"
1gh125
.138"
3gh187
.207"
2gh250
.276"
ABC
ABCD
ABCDE
ABCDEFGH
4 Characters
2 Lines
3 Characters
1 Line
2 Characters
1 Line
N/A N/A
4 Characters
2 Lines
3 Characters
1 Line
2 Characters
1 Line
2 Characters
1 Line
15
ON
LAD
END
DATA
ON
LAD
END
DATA
orDering inFormation
type of module Part
or legend number
1 Button 87CC3-201
2 Button 87DC3-201
3 Button 87eC3-201
4 Button 87FC3-201
5 Button 87gC3-201
6 Button 87hC3-201
12 Button–Matrix 87aB3-201
12 Button–
SP/Com Bus 87aC3-201
16 Button–Matrix 87BB3-201
16 Button–
SP/Com Bus 87BC3-201
Insertable Legend
Card
87aC2046
Dry Transfer–Small 87-Dt-2096-088
Dry Transfer–Medium 87-Dt-2096-125
Dry Transfer–Large 87-Dt-2096-187
Special legends
To order non-standard modules, information is
required for the areas listed below.
Your special order will be assigned a part
number for future identification. This number
is sequentially assigned and is non-descriptive.
1. type of module. 1, 2, 3, 4, 5, 6, 12 or 16
button.
2. mounting orientation. Horizontal or
vertical.
3. Circuitry. Single pole/common bus is standard
for all single row modules. For 12 or 16 button
keyboard, specify single pole/common bus or
matrix.
4. housing Color. Standard housing is black.
Optional stock colors include beige and
gray.
5. Button types. Flat or concave buttons
are available for molded legends; flat,
concave,
and snap-on cap styles
are available for printed legends.
6. Button Color. Standard buttons for molded
and printed legends are white with black
legend. Other colors available include white
legends with red, green, dark blue, dark
gray and black buttons, or black legends
with yellow, blue, light gray, beige and white
buttons. Additional legend colors such as
red are also available.
7. legend Style. Two-shot molded or printed.
Printed legends may be top or sub-surface
printed.
8. actual legend. Specify for each button
using the button identification on drawings.
Price–Contact Grayhill.
StanDarD legenDS
insertable Style modules
For prototypes and small quantities
Standard insertable legend modules are an
economical way to create your own keyboard
legend. Just remove the clear button cap, add
any legend, and replace the snap-on cap.
legend inserts
For insertable legend modules
Give your keyboard modules the appearance
of being printed without the cost. Self-adhesive,
printed legend inserts are die cut to fit the
buttons. Legend sheet includes commonly
used symbols, terms, alpha characters A-Z,
and numeric characters 0-99 in News Gothic
Condensed typestyle, printed in black on clear
backing. Legend sheets also include blank inserts
for dry transfer lettering.
87 Series Legend Sheet
Part no. 87aC2046
Dry transfer legends
For additional legend inserts
Sheets include A thru Z in upper and lower
case, the numeric characters 0 thru 9, as well
as commonly used symbols. The typestyle and
size are similar to the chart for printed legends
shown below.
Small Print
Part no. 87-Dt-2096-088
Medium Print Part no. 87-Dt-2096-125
Large Print Part no. 87-Dt-2096-187
SPeCial legenDS
Printed legends
For medium volume or short runs
Virtually any character, symbol or pattern which
can be photographed can be printed on the
button. Grayhill uses epoxy ink which bonds to
the surface of the button.
The legend can be printed on either of two
surfaces: the top surface of a one-piece button,
or the internal surface on the snap-on cap style
for maximum wear.
The typestyle chart shows the style and the
approximate limitations of Grayhill's standard
type. However, limitations differ with the surface to
be printed and the actual characters to be used.
If your legend exceeds the chart limits, contact
Grayhill for more information. Unless specified,
black legends are printed on white buttons.
additional ink Color: White ink is stocked for
use on dark colored buttons.
additional Button Colors: For a molding
charge, we can provide buttons from other colors
which we may have in stock, such as black,
red, green, blue, or yellow. Non-stock button/ink
colors may require minimum material purchase.
To order, or to check currently stocked colors,
contact Grayhill.
molded-in legends
For high volume production
For legends that will stand up to abuse and
constant wear for the life of your keyboard,
use molded-in legends. The two-shot molding
process molds the legend and button together.
Your special legend can be made from existing
Grayhill molds or we can tool special ones.
Buttons are available with black legends molded
in white or other light backgrounds, or with white
legends molded into dark backgrounds. See
Printed Buttons, Additional Button Colors. To order,
contact Grayhill.
