Standard Keypads
Keyboards and Keypads
orDering inFormation: StanDarD moDuleS
type of module Description Part no.
6 Buttons, SPST 82-601-85
6 Buttons, 2PST 82-601-86
6 Buttons, 3PST 82-601-87
6 Buttons, 4PST 82-601-88
6 Buttons, SPST 82-601-89
6 Buttons, 2PST 82-601-90
6 Buttons, 3PST 82-601-91
6 Buttons, 4PST 82-601-92
1 Button, SPST 82-101-71
1 Button, 4PST 82-101-74
2 Buttons, SPST 82-201-41
2 Buttons, 4PST 82-201-44
3 Buttons, SPST 82-301-61
3 Buttons, 4PST 82-301-64
6 Buttons, SPST 82-601-81
6 Buttons, 4PST 82-601-84
1 Button, SPST 82-150-17
1 Button, 2PST 82-150-15
3 Buttons, SPST 82-350-10
3 Buttons, 2PST 82-350-8
6 Buttons, SPST 82-650-10
6 Buttons, 2PST 82-650-8
1 Button, SPST 82-150-38
1 Button, 2PST 82-150-16
3 Buttons, SPST 82-350-12
3 Buttons, 2PST 82-350-9
6 Buttons, SPST 82-650-19
6 Buttons, 2PST 82-650-9
1 Button, SPST 82-150-211
1 Button, 2PST 82-150-213
3 Buttons, SPST 82-350-41
3 Buttons, 2PST 82-350-43
6 Buttons, SPST 82-650-71
6 Buttons, 2PST 82-650-73
White: For Unlighted Gray 82aC2017-1
Black: For Lightable Gray 82aC2050-1
Deadfront: For Lightable Black 82aC2060
Top Half of Telephone
Legend (Molded-in)
Bottom of Telephone
Legend (Molded-in)
Unlighted Gray Modules
For Legend Inserts
Lightable Gray Modules
Non-Legend
Lightable Gray Modules
For Legend Inserts
Lightable Black Modules
For Legend Inserts
Legend Sheets
available from your local grayhill Distributor. For prices and discounts, contact a local Sales
Office, an authorized local Distributor or Grayhill.
orDering inFormation:
Special legends
To order non-standard modules, information is
required for the areas listed below.
Your special order will be assigned a part
number for future identification. This number is
sequentially assigned and is non-descriptive.
1. type of module. Unlighted: 1-, 2-, 3-, or
6-button. Lightable: 1-, 3-, or 6-button.
2. mounting orientation. Horizontal or
vertical.
3. Circuitry. Requirements for each button must
be listed by its reference letter designation.
For example: Button A = SPST, Button B =
4PST, Button C = 3PST, etc. For coded or
other available circuitry patterns a descriptive
diagram is required for each button.
4. Button type (legend). Grayhill offers four
legend types: molded-in; top surface printed;
sub-surface printed; and insertable. Unlighted
modules are available in all types. Lightable
modules are available in all types but molded-
in legends.
5. Button Color. Standard color for molded-in
legend modules is gray button with white
legend. Special button colors available are
white with black legends, red, green or black
buttons with white legends. Additional custom
colors are available by special order.
Lightable gray modules have a standard
translucent white button with black legend.
Special button color includes translucent red,
amber, yellow, blue and green. Lightable black
modules have a special opaque black button;
discuss special colors with Grayhill.
Colors can be intermixed, ie. buttons A-E
gray; and F, white.
6. housing Color. Base in black. Upper housing
is black for lightable legends and gray for
all other module styles. Other stock colors
available include white, beige and brown.
7. legends. List legend requirement for each
button (Button A legend, "10", is type style
4GH088. Button B, "ON", is type style
1GH125, etc.). For legend information, see
page D-37.
Price: Contact Grayhill
