General Machine Products 70483 Hydraulically Limited Cable Puller - Manual (Page 2)

H
YDRAULICALLY
L
IMITED
F
IBER
O
PTIC
C
ABLE
P
ULLER
O
PERATION
T
ABLE OF
C
ONTENTS
1.0 GENERAL INFORMATION 2
2.0 SAFE OPERATING PRACTICES 3
3.0 TECHNICAL SPECIFICATIONS 3
4.0 COMPONENTS INCLUDED 3
5.0 OPTIONAL ACCESSORIES & REPLACEMENT ITEMS 4
& 5
6.0 OVERALL DIMENSIONS 6
7.0 KEY FEATURES 6
8.0 SETUP OF PULLER 6
& 7
8.1 HYDRAULIC CONNECTIONS 8
8.2 CALIBRATION 9
8.3 OPERATION 9
9.0 DISASSEMBLY AND STORAGE 10
10.0 CARE AND MAINTENANCE 10
11.0 TROUBLESHOOTING 11
1.0 G
ENERAL
I
NFORMATION
The GMP Hydraulically limited fiber optic cable puller is designed for
the underground placement of fiber optic cable. It uses a hydraulic
control valve with an adjustable pressure relief valve to limit the
hydraulic pressure to the hydraulic motor.
The GMP Hydraulically limited fiber optic cable puller comes complete with a
self support frame, hydraulic motor, (2) 20 ft. hydraulic hoses and an
adjustable foot control valve to control pulling tension and pulling speed.
Optional equipment includes a vehicle receiver mount with support jack for
mounting to a 2" square trailer hitch. Also available is a portable hydraulic power
unit with (2) 20 Ft. hydraulic hoses.
I
MPORTANT
P
RECAUTIONS
Read and understand all safety instructions, warnings and procedures prior to
using the GMP Hydraulically Limited Fiber Optic Cable Puller.
̈ THE HYDRAULICALLY LIMITED FIBER OPTIC CABLE PULLER IS NOT DESIGNED
FOR, NOR INTENDED TO BE USED FOR THE MOVEMENT OF PEOPLE. NEVER
USE THE PULLER FOR MOVING PEOPLE.
̈ THE HYDRAULICALLY LIMITED FIBER OPTIC CABLE PULLER IS NOT DESIGNED
FOR, NOR INTENDED TO BE USED TO PULL CABLE AERIALLY. NEVER USE THE
PULLER TO INSTALL CABLE ARIELLY.
̈ ESCAPING FLUIDS UNDER PRESSURE CAN PENETRATE THE SKIN AND CAUSE
SERIOUS PERSONAL INJURY.
2
