EXPLODED PRODUCT VIEW, PARTS & ORDERING INFORMATION
6AM SERIES
*** Item not shown.
∆ Denotes parts included in the Service Kit.
For specific OEM models, please consult the factory.
When corresponding about or ordering parts, please give complete model and serial numbers.
Exploded views are shown for reference only. Units may vary depending upon specific model.
REF# DESCRIPTION
QTY
6AM-FRV-5A
6AM-NRV-7A
6AM-NRV-22A 6AM-FRV-23A 6AM-ARV-54
6AM-ARV-55
6AM-NRV-11A
NEMA
1
DRIVE END CAP
1
AD642A
AD642A
AD642A
AD642A
AC988
AC988
AD642A
2 ∆
SHAFT SEAL
1
AC849
AC849
AC849
AC849
AK423
AK423
AC849
3 ∆
O-RING
1
AD649
AD649
AD649
AD649
AC989
AC989
AD649
4 ∆
DRIVE END BEARING
1
AD638A
AD638A
AD638A
AD638A
AC894B
AC894B
AD638A
5
DOWEL PIN
4
AB162
AB162
AB162C
AB162
AB162C
AB162C
AB162C
6
DRIVE END PLATE
1
AD651
AD666
AD667
AD651
AK424
AK424
AD667
7 ∆
BODY GASKET
2
AD641
AD641
AD641
AD641
AD641
AD641
AD641
8
BODY
1
AD650A
AD665
AD665
AD650A
AD665D
AD665D
AD665
9
KEY
1
AB136
AB136
AB136
AB136
AK422
AK422
AB136
10
ROTOR ASSEMBLY
1
AD652
AD652
AC398
AC779
AD648E
AD648D
AD648
11 ∆
PUSH PIN
2
AD655A
AD655A
AD655A
AD655A
4
AD655A
AD655A
AD655A
12 ∆
VANE SPRING
4
AD692
AD692
AD692
AD692
8
AD692
AD692
AD692
13 ∆
VANE
4
AD691
AD691
AD691
AD691
8
AD691
AD691
AD691
14
DEAD END PLATE
1
AD651
AD651
AD651
AD651
AD651
AD651
AD651
15 ∆
DEAD END BEARING
1
AB519
AB519
AB519
AB519
AB519
AB519
AB519
16 ∆
END CAP GASKET
1
AD644
AD644
AD644
AD644
AD644
AD644
AD644
17
DEAD END CAP
1
AD643
AD643
AD643
AD643
AD643
AD643
AD643
***
MUFFLER ASSEMBLY
1
AC990
AC990
AC990
AC990
AC990
AC990
AC990
***
MUFFLER FELT
1
AC993
AC993
AC993
AC993
AC993
AC993
AC993
***
SERVICE KIT
1
K208
K208
K281
K281
K281A
K281B
K208
