Gast DOA-P504-BN - Manual (Page 6)

PARTS & ORDERING INFORMATION
REF DESCRIPTION QTY DOA-P701-AA DAA-P501-EB*
DOL-701-AA DAA-V701-EB*
DOA-P501-BN
DOA-P501-JH
1 HEAD 1 AP500
2 AP500
2 ∆ HEAD O-RING 1 AP513
2 AP513
3 ∆ FILTER/MUFFLER ELEMENT 2 AT712A
4 AT712A
4 ∆ VALVE LIMITER 1 AP110
2 AP110
5 ∆ LEAF VALVE 2 AF817
4 AF817
6 VALVE PLATE 1 AP504
2 AP504
7 ∆ VALVE RETAINER 1 AF819A
2 AF819A
8 ∆ VALVE SCREW 1 BB330A
2 BB330A
9 RETAINER PLATE 1 AF809
2 AF809
10 DIAPHRAGM–COMPRESSOR 1 AF818A
2 AF818A
10 DIAPHRAGM–VACUUM 1 AF818B
2 AF818B
11 FELT SPACER 3 AA929
3 AA929
12 SPACER 1 AD996
2 AD996
13 FAN - DOA, DOL 1 AF533 AF533
FAN - DAA 1 AF533A
14 GRILLE 1 AF807
2 AF807
15 RIVET 4 AP534
8 AP534
16 VALVE PLATE ASSEMBLY 1 AP519
2 AP519
17 CRANKCASE COVER 1 AP526
2 AP526
18 CRANKCASE COVER SCREW 2 AP525
4 AP525
*** SERVICE KIT 1 K294A
2 K294A
DAA / DOA / DOL SERIES
Please reference the exploded views on the next page for the following model and parts table.
* DOA shown. The double-ended DAA models (not illustrated) are two DOAs mounted back to back with heads rotated.
*** Item not shown.
∆ Denotes parts included in the Service Kit.
∆ The service kit may contain parts for more than one model or style diaphragm pump.
Parts not needed may be discarded.
Parts listed are for stock models. For specific OEM models, please consult the factory.
When corresponding or ordering parts, please give complete model and serial numbers.
6
