Gast PCD - Manual (Page 10)

VBB – PCA-10 SERIES
Models PAB and PBB shown.
** Item not shown.
∆
Denotes parts included in the Service Kit.
Parts listed are for stock models. For specific OEM models, please consult the factory.
When corresponding or ordering parts, please give complete model and serial numbers.
PARTS & ORDERING INFORMATION
REF DESCRIPTION QTY PAB VAB
1 FILTER ASSEMBLY 1 B300A B300A
2 ∆ FELT 1 B344A B344A
3 SAFETY VALVE 1 AS100G –
4 CYLINDER HEAD 1 AF508 AF508
5 ∆ HEAD GASKET 1 AF518 AF518
6
∆
OUTLET VALVE 1 AF531 AF531
7 PLATE VALVE 1 AF529 AF529
8 ∆ INLET VALVE 1 AF530 AF530
9 ∆ CYLINDER GASKET 1 AF519A AF519A
10 CYLINDER 1 AF510 AF510
11
∆
PISTON RING 2 AF527 AF527
12 ∆ PISTON SEAL 2 AF526 AF526
13
∆
RIDER RING 1 AF594 AF594
14 PISTON ROD ASSEMBLY 1 AF560B AF560B
15 PULLEY 1 AB140C AB140C
15A COUNTER WEIGHT 1 AF517B AF517B
16 FLAT KEY 1 AF524 AF524
17 FAN 1 AF533 AF533
18 SHROUD 1 AF534 AF534
*** SERVICE KIT 1 K264 K264
PAB – VAB SERIES
REF DESCRIPTION QTY VBB VCD PBB PCA-10
1 FILTER ASSEMBLY 2 B300A B300A B300A B300F
2 ∆ FELT 2 B344A B344A B344A B344A
3 SAFETY VALVE 1 – – AS100G AS100H
4 CYLINDER HEAD 2 AF508 AF507 AF508 AF507
5
∆
HEAD GASKET 2 AF518 AF520A AF518 AF520A
6 ∆ OUTLET VALVE 2 AF531 AF545 AF531 AF545
7 PLATE VALVE 2 AF529 AF543 AF529 AF543
8 ∆ INLET VALVE 2 AF530 AF544 AF530 AF544
9 ∆ CYLINDER GASKET 2 AF519A AF521 AF519A AF521
10 CYLINDER 2 AF510 AF509 AF510 AF509
11 ∆ PISTON RING 4 AF527 AF541 AF527 AF541
12
∆
PISTON SEAL 4 AF526 AF540 AF526 AF540
13 PISTON ROD ASSEMBLY 2 AF560B AF561D AF560B AF561A
14 ∆ RIDER RING 2 AF594 AF595 AF594 AF595
15 PULLEY 1 AB140C AK670 AB140C AK670
16 FLAT KEY 1 AF524 AB136 AF524 AB136
17 FAN 1 AF533 AF547 AF533 AF661
18 SHROUD 1 AF535 AF549 AF535 AF656
19 MANIFOLD SLEEVE 2 AF567A AF567A AF567A AF567A
*** SERVICE KIT 1 K260 K263 K260 K263
Please reference the exploded views on the next page for the following model and parts tables.
