Dimensions and Technical Specifications RTCSmp Tabletop Temperature Controlled Hold-Line
8 Part # 4532289 Rev 2 (1/17/14)
3 Dimensions and Technical Specifications
3.1 Rating Plate
The rating plate specifies important information such as model number,
serial number, and electrical specifications. The rating plate is affixed to
the bottom of the unit, next to the air intake and air deflector.
3.2 Nomenclature and Model
Series Power (Watt) Voltage (Volt) Model
HO = Hold Line 1500 120 HO1500-120
3.3 Electrical Specifications
Model Voltage Power No. of Heat Retaining Zones
HO1500 120 V AC / 1Ph 1500 W (2x 750W) / 12A 2
3.4 Dimensions
Model Glass Top Only (width x depth x height) Overall Dimensions (width x depth x height) Weight
HO1500 31.50” x15.75” x0.169” (800 x400 x4 mm) 31.50” x 15.75” x 4.49” (800 x 400 x 114 mm) 17kg/ 37.5lb
Dimensions: RTCSmp Tabletop Hold-Line HO1500
