GUIDE TO FLEX FASTENER AND FLEX PLATE PLACEMENTS
This guide is based on current FM Approvals for the field sheet
securement criteria.
Steel Deck or Structural Concrete
Membrane
Type
Row
Spacing
Fastener
Type
Fastener
Spacing
Uplift
Rating (psf)
TPO Plus 42.5” XHD 12” 105
TPO Plus 42.5” XHD 6” 165
TPO Plus 91” SXHD 12” 90
TPO Plus 91” XHD 6” 105
TPO Plus 91” XHD 12” 60
TPO Plus 115” XHD 12” 75
TPO Plus 115” SXHD 12” 90
TPO Plus 115” XHD 6” 105
TPO Plus 115” XHD 6” 120
TPO Plus 115” XHD 12” 60
TPO Plus 138.5” SXHD 6” 120
Acceptable steel decks must meet the following
minimum requirements:
Must be 18, 20, or 22 gauge thickness, 1.5” deep.
Deck installation is to be in accordance with Factory
Mutual requirements.
Structural Concrete decks require the use of
Flex CD-10 or Flex HD 10-14 fasteners with the
appropriate Flex seam plate.
6
