Inspection and service
Warning! Loss of the safety function because of
damage to the system.
In case of damage, the related component must
be replaced completely.
Only accessories or spare parts that can be ordered
from EUCHNER may be replaced.
Regular inspection of the following is necessary to
ensure trouble-free long-term operation:
f
Check the switching function
f
Check the secure fastening of the devices and
the connections
f
Check for soiling
Check the safe function of the safety guard par-
ticularly
f
after any setup work
f
after the replacement of a CET component
f
after an extended period without use
f
after every fault
No servicing is required, repairs to the device are
only allowed to be made by the manufacturer.
Technical data (extract)
Parameter Value
Material
- Slide
- Safety switch housing
Stainless steel
Die-cast aluminum
Mechanical life 1 x 10 6 operating cycles
Ambient temperature
at U
B
= DC 24 V
-20 .... +55 °C
Locking force F
max.
6500 N
Locking force F
Zh
in accordance with
test principles GS-ET-19
F
Zh
=
F
max
1,3
= 5000 N
Connection 2 plug connectors M12,
5- and 8-pin
or 1 plug connector RC 18
Operating voltage U
B
(reverse polarity protected,
regulated, residual ripple
< 5 %)
DC 24 V ±15%
Current consumption I
B
80 mA
Max. switching delay from
state change
400 ms
Max. difference time between
the two safety outputs
10 ms
Safety outputs OA/OB Semiconductor outputs, p-
switching, short circuit-proof
Output voltage U(OA)/U(OB) 1)
HIGH U
(OA)
/ U
(OB)
U
B
-1.5 V ... U
B
LOW U
(OA)
/U
(OB)
0 ... 1 V DC
Switching current
per safety output
1 ... 200 mA
Utilization category
according to
EN IEC 60947-5-2
DC-13 24 V 200 mA
Caution: outputs must be
protected with a free-wheeling
diode in case of inductive
loads.
Performance Level
in accordance with
EN 13849-1
PL e
Classification
acc. to EN IEC 60947-5-3
PDF-M
Switching frequency 0.5 Hz
Solenoid
Solenoid operating voltage U
CM
(reverse polarity protected,
regulated, residual ripple
< 5 %)
DC 24 V +10%/-15%
Current consumption
solenoid I
CM
480 mA
Power consumption 10 W
Duty cycle 100 %
Reliability values
according to EN ISO
13849-1
Head downward
or horizontal
Head upward
Category 4 3
Performance Level (PL) e e
PFH
d
3.1 x 10 -9 / h 4.29 x 10 -8 / h
Mission time (years) 20 20
