Operating Instructions Safety Switch CES-AR-C01-EH-SA
27
Ordering information and accessories
Designation Version Order
No.
CES-AR-C01-EH-SA including
actuator
fixcode 098582
Bridging plug M12, 4-pin, plug 097645
Y-distributor M12, 1x8-pin, 2x5-pin 097627
Y-distributor with connecting cable M12, 1x8-pin, 2x5-pin, length 200 mm 111696
M12, 1x8-pin, 2x5-pin, length 1,000 mm 112395
Connection cable PVC 8-core,
flying lead
M12, 8-pin, 5 m 100177
M12, 8-pin, 10 m 100178
M12, 8-pin, 20 m 100179
Tip!
You will find further connection material, in particular for series connection, in the
current Non-Contact Safety System CES catalog at www.euchner.de.
Inspection and service
Warning!
Loss of the safety function because of damage to the system.
The complete device including actuator must be replaced in the event of damage.
Only accessories or spare parts that can be ordered from EUCHNER may be
replaced.
Regular inspection of the following is necessary to ensure trouble-free long-term
operation:
Ì Check the switching function (see section Functional check)
Ì Check the secure fastening of the devices and the connections
Ì Check for soiling
No servicing is required; repairs to the device are only allowed to be made by the
manufacturer.
Note:
The year of manufacture can be seen in the lower right corner of the rating plate.
The current version number in the format (V X.X.X) can also be found on the device.
The safety door must be re-adjusted when the device indicates that the actuator
is in the limit range.
