Operating Instructions Safety Switch CES-I-AP-U-C04
24
Ordering information and accessories
Designation Version Order no.
CES-I-AP-U-C04-USI-115150 Safety switch, unicode, connection cable PUR 100 mm with M12 plug connector, 5-pin, pin 5 not used 115150
CES-I-AP-U-C04-U05-116503 Safety switch, unicode, with monitoring output OD, connection cable PUR 5 m, flying lead 5 x 0.25 mm² 116503
CES-I-AP-U-C04-U10-116504 Safety switch, unicode, with monitoring output OD, connection cable PUR 10 m, flying lead 5 x 0.25 mm² 116504
CES-I-AP-U-C04-U20-116505 Safety switch, unicode, with monitoring output OD, connection cable PUR 20 m, flying lead 5 x 0.25 mm² 116505
CES-I-AP-U-C04-USB-116502 Safety switch, unicode, with monitoring output OD, connection cable PUR 220 mm with M12 lug connector, 5-pin 116502
CES-I-AP-U-C04-SK-115324 Safety switch, unicode, M8 plug connector, 4-pin 115324
CES-A-BBN-C04-115271 Actuator 42 x 25 x 18 mm 115271
CES-A-BDN-06-104730 Actuator 26 mm x ∅ 6 mm 104730
Inspection and service
Warning!
Loss of the safety function because of damage to the system.
In case of damage, the related component must be replaced completely.
Only accessories or spare parts that can be ordered from EUCHNER may be
replaced.
Regular inspection of the following is necessary to ensure trouble-free long-term
operation:
Ì Check the switching function (see section Functional check)
Ì Check the secure fastening of the devices and the connections
Ì Check for soiling
No servicing is required. Repairs to the device are only allowed to be made by
the manufacturer.
Note!
The year of manufacture can be seen in the lower right corner of the rating plate.
The current version number in the format (V X.X.X) can also be found on the device.
The safety door must be re-adjusted when the device indicates that the actuator
is in the limit range.
Service
If service support is required, please contact:
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16
D-70771 Leinfelden-Echterdingen
Service telephone:
+49 711 7597-500
E-mail:
[email protected]
Internet:
www.euchner.de
