Safety information and Maintenance
(Part of the Operating Instructions for Safety System CES-A…/CES-AZ/CES-FD)
Subject to technical modifications; no r
esponsibility is accepted for the accuracy of this information. © EUCHNER GmbH + Co. KG 109083-05-11/13 (translation of the o
riginal operating instructions)
EN
Correct Use
The Coded Electronic Safety systems series CES are
safety devices for monitoring movable safety guards.
In combination with a separating safety guard, this
safety component prevents dangerous machine
movements from being performed for as long as the
safety guard is open. A stop command is triggered
if the safety guard is opened during the dangerous
machine function.
Before safety components are used, a risk assess-
ment must be performed on the machine, e.g., in
accordance with:
f
EN ISO 13489-1, Safety of machinery. Safety re-
lated parts of control systems. General principles
for design
f
EN ISO 12100, Safety of machinery - General
principles for design - Risk assessment and risk
reduction
f
IEC 62061, Safety of machinery – Functional safety
of safety-related electrical, electronic and program-
mable electronic control systems.
Correct use includes compliance with the relevant re-
quirements for installation and operation, for example
f
EN ISO 13489-1, Safety of machinery. Safety re-
lated parts of control systems. General principles
for design
f
EN 1088, Safety of machinery. Interlocking devices
associated with guards. Principles for design and
selection
f
EN 60204-1, Safety of machinery. Electrical equip-
ment of machines. General requirements
f
EN 60947-5-3, Specification for low-voltage switch-
gear and controlgear. Control circuit devices and
switching elements. Requirements for proximity
devices with defined behaviour under fault condi-
tions (PDF)
The evaluation unit must be used only in conjunction
with the designated read heads and actuators from
EUCHNER. On the use of different read heads and
actuators, EUCHNER provides no warranty for safe
function.
A combination of other CES devices or devices from
other manufacturers is not allowed.
Important: The user is responsible for the integra-
tion of the device in a safe overall system. For this
purpose, the overall system must be validated, e.g.
in accordance with EN ISO 13849-2.
If a product data sheet is included with the product,
the information on the data sheet applies in case of
discrepancies with the operating instructions.
No servicing is required. Repairs to the device are only
allowed to be made by the manufacturer.
Technical data (extract)
f Evaluation units CES‑A and CES‑AZ
Parameter Value
Operating voltage U
B
see rating plate of the device
Current consumption see rating plate of the device
External fuse
(operating voltage U
B
)
CES-…-01B 0.25 … 8 A
CES-…-02B/04B 0.40 … 8 A
External fuse
Safety circuit
(13-14 / 23-24)
max. 6 A gG
or 6 A circuit breaker (char. B or C)
Safety outputs
13-14 / 23-24 2 outputs, relays with internally moni-
tored contacts, see rating plate of the
device for the utilization category
Assured switch-off
distance s
ar
max. 60 mm
(Combination of evaluation unit
CES-A(Z)-xxx-xxB with read head
CES-A-LQA-SC and actuator
CES-A-BQA; see operating instructions
or data sheet of the respective read
head/actuator for other combinations)
Connection example see rating plate of the device
Reliability figures according to EN ISO 13849‑1
Switching current
at 24 V DC
≤ 0.1 A ≤ 1 A ≤ 3 A
CES‑A‑ABA‑…
CES‑A‑UBA‑…
CES‑AZ‑ABS‑…
CES‑AZ‑UBS‑…
Category
3
PL e
PFH
d
4.3 x 10 -8
Mission time 20 years
Switching cycles/year 760 000 153 000 34 600
CES‑A‑AEA‑…
CES‑A‑UEA‑…
Category
4
PL e
PFH
d
1.3 x 10 -8 1.5 x 10 -8
Mission time 20 years
Switching cycles/year 506 000 100 000 23 000
CES‑AZ‑AES‑01B
CES‑AZ‑AES‑02B/04B
CES‑AZ‑UES‑01B
CES‑AZ‑UES‑02B/04B
Category
4
PL e
PFH
d
1.9 x 10 -8
Mission time 20 years
Switching cycles/year 760 000 153 000 34 600
f Field evaluation unit CES‑FD
Parameter Value
min. typ. max.
Operating voltage U
B
(reverse polarity protected,
regulated, residual ripple < 5 %) DC 24 V ± 15% (PELV)
Current consumption 45 mA
External fuse (operating voltage) 0.25 A - 1.5 A
Safety outputs FO1A/FO1B Semiconductor outputs,
p-switching,
short circuit-proof
- Output voltage
HIGH
U
B
-1.5 - U
B
LOW 0 V 1 V
Switching current per safety output 1 mA - 150 mA
Assured switch-off distance s
ar
- with read head CES-A-LMN-SC and
actuator CES-A-BMB
- - 10 mm
- with key adapter
CKS-A-L1B-SC-113130 and
key CKS-A-BK1-RD-113461
- - 35 mm
Reliability figures according to EN ISO 13849‑1
CES‑FD‑AP‑…
Categorie
4
PL e
PFH
d
4.5 x 10 -9 / h
Mission time 20 years
f Feldauswertegerät CES‑FD
Parameter Wert
min. typ. max.
Betriebsspannung U
B
(verpolsicher,
geregelt, Restwelligkeit < 5 %)
DC 24 V ± 15% (PELV)
Stromaufnahme 45 mA
Absicherung extern (Betriebsspannung) 0,25 A - 1,5 A
Sicherheitsausgänge FO1A/FO1B Halbleiterausgänge,
p-schaltend,
kurzschlusssicher
- Ausgangsspannung
HIGH
U
B
-1,5 - U
B
LOW 0 V 1 V
Schaltstrom je Sicherheitsausgang 1 mA - 150 mA
Gesicherter Ausschaltabstand s
ar
- mit Lesekopf CES-A-LMN-SC und
Betätiger CES-A-BMB
- - 10 mm
- mit Schlüsselaufnahme
CKS-A-L1B-SC-113130 und
Schlüssel CKS-A-BK1-RD-113461
- - 35 mm
Zuverlässigkeitswerte nach EN ISO 13849‑1
CES‑FD‑AP‑…
Kategorie
4
PL e
PFH
d
4,5 x 10 -9 / h
Gebrauchsdauer 20 Jahre
Exclusion of Liability and Warranty
In case of failure to comply with the conditions for cor-
rect use stated above, or if the safety instructions are
not followed, or if any servicing is not performed as re-
quired, liability will be excluded and the warranty void.
General Safety Instructions
The device is only allowed to be installed and placed
in operation by authorized personnel
f
who are familiar with the correct handling of safety
components,
f
who are familiar with the applicable regulations on
health and safety
f
and who have read and understood the operating
instructions.
The safety function of the system while the machine
is in operation can no longer be ensured if the device
is connected incorrectly or used incorrectly.
Prior to use, read the operating instructions on the
CD/DVD supplied, and keep these in a safe place.
Ensure the operating instructions are always avail-
able during mounting, setup and servicing.
EUCHNER cannot provide any warranty in relation to
the readability of the CD/DVD for the storage period
required. For this reason you should archive a printed
copy of the operating instructions. You can download
the operating instructions at www.EUCHNER.de.
Operating instructions on CD/DVD
Each device is supplied with operating instructions
on CD/DVD; these instructions contain detailed infor-
mation on the overall system. The following system
requirements must be met to be able to open or print
the document:
f
PC with PDF Reader installed
f
CD/DVD drive
f Opening and printing the documents
Important: the autoplay function for the drive must be
enabled (see operating system help) and you will need
a PDF Reader that can open PDF files from version 4.
1. Insert CD/DVD
¨ Selection table is opened in the browser
2. Click the related document for your system
¨ The document is opened and can be printed
Mounting, setup and troubleshooting
For detailed instructions on mounting, setup and
troubleshooting, please refer to the operating instruc-
tions on the CD/DVD.
Electrical connection
For detailed information on the electrical connec-
tion, please refer to the operating instructions on
the CD/DVD.
Important: To achieve the stated category accord-
ing to EN ISO 13849-1, both safety outputs must
always be evaluated with individual devices.
Take note of the connection example in the operating
instructions on CD/DVD.
Inspection and Service
Warning! Loss of the safety function because of
damage to the system.
In case of damage, the related component must be
replaced completely.
Only accessories or spare parts that can be ordered
from EUCHNER may be replaced.
Regular inspection of the following is necessary to
ensure trouble-free long-term operation:
f
Check the switching function
f
Check the secure fastening of the devices and the
connections
f
Check for soiling
Check the safe function of the safety guard par-
ticularly
f
after any setup work
f
after the replacement of a CES component
f
after an extended period without use
