Operating Instructions Safety Switches TP...
f Electrical function test
1. Switch on operating voltage.
2. Close all safety guards.
Guard locking by solenoid force:  Activate
guard locking.
f
The machine must not start automatically.
f
It must not be possible to open the safety guard.
3. Enable operation in the control system.
f
It must not be possible to deactivate the guard
locking as long as operation is enabled.
4. Disable operation in the control system and
deactivate guard locking.
f
The safety guard must remain locked until there is
no longer any risk of injury.
f
It must not be possible to start the machine as long
as the guard locking is deactivated.
Repeat steps 2 - 4 for each safety guard.
Inspection and Service
If damage or wear is found, the complete switch
and actuator assembly must be replaced.
Replacement of individual parts or assemblies
is not permitted!
No servicing is required, but regular inspection
of the following is necessary to ensure trouble-free
long-term operation:
f
correct switching function
f
secure mounting of components
f
dirt and wear
f
sealing of cable entry
f
loose cable connections or plug connectors.
Note:The year of manufacture can be seen in the
bottom, right corner of the rating plate.
Exclusion of Liability under the Following
Conditions
f
if the unit is not used for its intended purpose
f
non-compliance with safety regulations
f
non-compliance with safety regulations
f
failure to perform functional checks.
EC declaration of conformity
The manufacturer named below herewith declares
that the product fulfills the provisions of the
directive(s) listed below and that the related standards
have been applied.
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16
70771 Leinfelden-Echterdingen, Germany
Directives applied:
f
Machinery directive 2006/42/EC
Standards applied:
f
EN 60947-5-1:2004 + Cor.:2005 + A1:2009
f
EN 1088:1995+A2:2008
Leinfelden, April 2010
Dipl.-Ing. Michael Euchner
Director
Duc Binh Nguyen
Authorized representative empowered to draw up
documentation
The signed EC declaration of conformity is included
with the product.
Electrical Connection
When choosing the insulation material and wire
for the connections, pay attention to the over-
temperature in the housing (depending on the
operating conditions)!
Only switching contacts marked with the posi-
tively driven NC contact symbol are to be used
for the safety circuit.
For switching elements with four positively driven
NC contacts only the contacts 21-22 and 41-42
are actuated on activating and deactivating the
guard locking. In applications with potentially haz-
ardous states (e.g. overtravelling movements),
contact 21-22 and/or 41-42 must always be
integrated into the safety circuit.
For TP with plug connector:
For use and applications as per the requirements of
, a class 2 power supply or a class 2 transformer
according to UL1310 or UL1585 must be used.
Connection cables for safety switches installed at the
place of use must be separated from all moving and
permanently installed cables and un-insulated active
elements of other parts of the system which operate
at a voltage of over 150 V. A constant clearance of
50.8 mm must be maintained. This does not apply if
the moving cables are equipped with suitable insula-
tion materials which possess an identical or higher
dielectric strength compared to the other relevant
parts of the system.
For TP without plug connector:
For use and applications as per the requirements of
, copper wire 60/75 °C is to be used.
The operating voltage for the interlocking solenoid
must match the value on the rating plate (e.g.
U
S
= AC/DC 24 V).
f Version TP.. (cable entry M20x1.5/PG 13.5/
NPT ½“)
f
Break out the required entry opening.
f
Fit the cable gland with the appropriate degree of
protection.
f
For pin assignment see Figure 3.
f
Tighten the screws with a torque of 0.5 Nm.
f
Check that the cable entry is sealed.
f
Close the cover and screw in position.
f Version TP..SR.. (plug connector)
f
For pin assignment see Figure 3.
Functional Check
Warning! Danger of fatal injury as a result of faults
in installation and functional check.
Before carrying out the functional check, make
sure that there are no persons in the danger
area. Observe the valid accident prevention
regulations.
After installation and any fault, the safety function
must be fully checked. Proceed as follows:
f Mechanical function test
The actuator must slide easily into the actuating
head. Close the safety guard several times to check
the function.
Technical Data
Parameter Value
Housing material Reinforced thermoplastic
Degree of protection according to IEC 60529
Cable entry
IP67
Plug connector IP65
Mech. Mechanical life 1 x 10 6 operating cycles
Ambient temperature -20 ... +55°C
Degree of contamination
(external, according to
EN 60947-1)
3 (industrial)
Installation position Any
Approach speed, max. 20 m/min
Actuating force, max.
at 20°C
10 N
Extraction force 20 N
Retention force 10 N
Locking force F
max
TP1/TP2/TP3/TP4 1,300 N
TP5/TP6 800 N
Locking force F
Zh
in accordance with test principles GS-ET-19
TP1/TP2/TP3/TP4
(F
Zh
=
F
max ) = 1,000 N
1,3
TP5/TP6 –
Actuation frequency 1,200/h
Switching principle Slow-action switching contact
Contact material Silver alloy, gold flashed
Connection type
TP...
Screw terminal with cable entry
TP...SR6 SR6 plug connector; 6-pin + PE
TP...SR11 SR11 plug connector; 11-pin + PE
Conductor cross-section
(rigid/flexible)
0.34 ... 1.5 mm²
Rated insulation voltage
TP... , TP...SR6
U
i
= 250 V
TP...SR11 U
i
= 50 V
Rated impulse withstand voltage
TP... , TP...SR6
U
imp
= 2.5 kV
TP...SR11 U
imp
= 1.5 kV
Rated short-circuit current 100 A
Switching voltage, min.
at 10 mA
12 V
Utilization category to EN 60947-5-1
TP... , TP...SR6
AC-15 4 A 230 V / DC-13 4 A 24 V
TP...SR11 AC-15 4 A 50 V / DC-13 4 A 24 V
Switching current, min., at 24 V 1 mA
Short circuit protection
to IEC 60269-1
4 A gG
Conv. thermal current I th 4 A
Solenoid operating voltage/solenoid power consumption
TP...024
AC/DC 24 V (+10%/-15%) 8 W
TP...110 AC 110 V (+10%/-15%) 10 W
TP...230 AC 230 V (+10%/-15%) 11 W
Duty cycle 100 %
Reliability figures according to EN ISO 13849-1
B
10d 3 x 10 6
