ETC Unison Mosaic MediaManager v1.0.3 - Manual (Page 20)

Unison Mosaic MediaManager User Manual
Simulation
The programming on each media slot can be simulated for each of the pixel matrices on which the media slot was
used in Pharos Designer.
Selecting a Pixel Matrix
The current pixel matrix number is displayed on the application toolbar, along with the total number of pixel
matrices on which the selected media slot is used. Use the arrow buttons to change the current pixel matrix.
Adjusting the Simulation View
l
Zoom In: click
l
Zoom Out: click
l
Pan: click and drag to pan the simulation view, or use the scroll bars.
l
Show Used Pixels: click to enable this feature. Click again to disable.
l
Background Colour: this can be changed in the Preferences dialog.
Simulation Playback
Use the simulation playback buttons on the application toolbar.
l
Play:
l
Pause:
l
Stop:
l
Seek Forwards:
l
Seek Backwards:
The current point in time for the simulation is shown on the application toolbar.
- 20 -
