ETC Unison Mosaic MediaManager v1.0.3 - Manual (Page 18)

Unison Mosaic MediaManager User Manual
Programming
Media presets can be programmed onto the selected media slot. Transitions can be set up between media pre-
sets.
If the total length of programming on a media slot is less than the length of the media slot then the content will
loop when played back by Controllers. If the total length of programming on a media slot is greater than the
length of the media slot then some cropping will occur.
Adding a Media Preset to a Media Slot
l
Select the media slot to program from the media slot browser on the left of the application window.
l
Click and drag a media preset from the media preset library and drop it onto the media slot timeline at the
bottom of the application window.
Reordering Media Presets on a Media Slot Timeline
Click and drag a media preset on the timeline of a media slot to change its position in the timeline.
Editing the Length of a Media Preset
Enter the new length into the length editor of the media preset on the media slot timeline. If the length is longer
than the length of the media preset source then the media preset will loop.
Click next to the length editor of the media preset on the media slot timeline to reset the length to the default
value.
Editing the Transition of a Media Preset
Click within the media preset on the media slot timeline. The transition editor dialog will appear.
Transition Properties
l
Time: the duration of the transition. This cannot be more than the length of the media preset.
l
Type: how the media presets should blend into each other.
- 18 -
