2.02

Panel System shall be the Englert Series 2500, 2” high, 16” wide, Structural Standing Seam System (with ribs).
Mechanical seaming available in 45, 90, & 180 degrees. The panels shall have baked on finish as specified in
Section 2.05 hereunder, in manufacturer’s standard colors. Manufacturer shall offer at least a minimum of 23
standard colors to choose from.

Substrate:

24 Gauge baked on finish over Galvalume ASTM A-792-83, AZ50, 50 KSI yield point.

26 Gauge baked on finish over Galvalume ASTM A-792-83, AZ50, 50 KSI yield point.

* .032” or .040” Aluminum Alloy 3105-H14 approved equal.

NOTE TO SPECIFIER: *22 gauge steel, and .032” and .040” aluminum are available subject to minimum order
requirements. Call Englert for details.

Performance:

1. Panel shall meet the requirements of Underwriter’s Laboratories, Inc. for Class 90 wind uplift resistance.
2. ASTM E-283-84 Air Infiltration: Maximum of 0.006 CFM/Ft2 at 1.57 psf pressure differential on 45 degree seamed

profile and 0.013 CRM/Ft2 at 6.24 psf pressure differential.

3. ASTM E-331-70 Water Penetration: No evidence of uncontrolled leakage on 45 degree seamed panel at 15.10 psf

pressure differential.

4. Panel shall display a flame spread classification of a Class 1, when tested in accordance with ASTM E-84-87
5. Panel shall have been tested and rated in accordance with ASTM-E-1592 structural performance of sheet metal

roof and siding systems by uniform static air pressure difference in 24 gauge steel and .040” aluminum.

6. Panel shall have been tested and rated in accordance with Factory Mutual Research Corporation’s Class 4471

wind uplift testing; minimum rating of FMI90.

7. ASTM-E-1680-95 standard method for rate of air leakage through exterior metal roof panel systems.
8. ASTM-E-1646-95 standard test method for water penetration of metal roof systems by uniform static air pressure

differential.

Florida Building Code product approval.

IF METAL SOFFIT IS REQUIRED, SPECIFY AS FOLLOWS:

2.03 SOFFIT PANEL SYSTEMS

Soffit Panels: Series 2500 is not recommended for use as a soffit system.

2.04 FABRICATION

Panel Construction: Panels shall be uniformly dimensioned, rollformed to exact lengths to avoid trimming. The panel
system shall be anchored as recommended by the Manufacturer. All fasteners shall be concealed. Panels shall be
continuous from ridge to eaves with no end laps. There shall be no face penetration of panels, except as approved by
the architect for securing panels to facilitate directional expansion/contraction.

Flashing and Trim: All exposed standard or special flashing/trim and such other brakeformed in the same gauge,
color, and finish to match roofing panels, furnished with protective strippable film to be removed upon installation.

Accessories such as clips, closures, fasteners, etc., shall be as recomme nded by the Manufacturer.

2.05 PERMACOLOR 3500 FINISH - (35-Year Warranty)

Englert’s PermaColor 3500 standard 35-year color coatings comprises of a .8 to .9 mil full strength 70% Kynar 500
fluorocarbon (Polyvinylidene Fluoride PVF2) coating over a urethane primer of. 2 to .3 mil on the finish side, with
primer and a wash coat on the reverse, on steel with just a wash coat on aluminum. Face film thickness 1.0 mil + .2 mil.
