Gold Drum HV Cable Kit (EtherCAT and CAN)

MAN-G-DRUHV-CBLKIT (Ver. 1.000)

www.elmomc.com

9

Pin Positions

15-Pin D-Type Female Connector

15-Pin D-Type Male

Connector

Note:

The specific functionality of each pin is described fully in the Gold Drum HV Installation

Guide.

Figure 3: Feedback Port A Cable
