Gold Drum HV Cable Kit (EtherCAT and CAN)
MAN-G-DRUHV-CBLKIT (Ver. 1.000)
www.elmomc.com
4
Chapter 1: Introduction
This document provides the wiring details for the cables used to connect Elmo's Gold Drum HV
servo drive with the end-user application. The servo drive-side pinouts are provided in the
Gold Drum HV Installation Guide.
The cables come in one length: 2 meters (6 ½ feet).
NOTE:
It should be noted that this kit does not include any CAT5E RJ-45 for EtherCAT/CAN and
Mini-USB communication cables. Please purchase these cables separately. These items are
standard cables that can be purchased locally.
Elmo's Gold Drum HV Cable Kit consists of two sets of cable kits:
ELMO Part Number Function
DRU-HVPOWKIT Power cable kit for the Gold Drum HV
See Chapter 2: Gold Drum HV Power Cable Kit
for more details
G-CON D-SUBKIT Gold Control D-Sub cable kit
See Chapter 3: Gold Drum HV Control D-Sub for
more details
