Gold Drum HV Cable Kit (EtherCAT and CAN)

MAN-G-DRUHV-CBLKIT (Ver. 1.000)

13

Pin Positions

15-Pin High Density Female D-Type Connector

15-Pin High Density

D-Type Male

Connector

Note:

The specific functionality of each pin is described fully in the Gold Drum HV Installation

Guide.

Figure 5: Port C Cable
