Gold Solo Whistle Cable Kit
MAN-G-SOLWHI-CBLKIT (Ver. 1.201)
www.elmomc.com
4 4
Chapter 1: Introduction
This document provides the wiring details for the cables used to connect the Gold Solo Whistle
with the end-user application. The servo drive-side pinouts are provided in Chapter 3 of the
drive’s installation guide.
The cables come in one length: 2 meters (6 ½ feet).
Note: CAN, EtherCAT, and RS-232 communication cables are not included in the
CBL-GSOLWHIKIT01 cable kit.
1.1. Cable Kit (CBL-GSOLWHIKIT01)
The Catalog number of the Gold Solo Whistle cable kit is CBL-GSOLWHIKIT01
The cable kit includes the following cables:
ELMO Part Number Function
CBL-GPORTA-A2 Feedback port A
CBL-GPORTB-A2 Feedback port B
CBL-GPORTCIO-A2 Port C and I/O
CBL-GSTOCOM-A2 STO
CBL-GVLSNS-A2 Auxiliary Power Cable
