7
6000-200E Monitor Nozzle Parts List
INDEX NO. PART NO.
QUANTITY PER
UNIT DESCRIPTION
1 81197001 1 Nozzle Actuator 12V
2 61078000 1 Screw #10-32 x 0.250 lg S/S
3 69076007 1 Nozzle Stem
4 16575310 1 Bumper
5 66432007 1 Nozzle Tip
6 17729001 1 Push Rod Bracket
7 44618000 1 Info Label
8 57319000 1 O-ring 1.925 ID x 0.103 C/S
9 61040000 1 Socket Cap Screw 0.25-20 x 0.500 lg S/S
10 18117007 1 Center Barrel
11 51063000 1 Drive Pin 0.125 Dia x 0.625 lg Type C S/S
12 57521000 1 O-ring 1.364 ID x 0.070 C/S
13 61762000 1 Coil Spring
14 44064105 1 Locking Lever
15 33083000 1 2.5 Swivel Gasket
16 63674000 1 Set Screw 0.375-24 x 0.156 lg Teflon
17 63069007 1 2.5 R/L Swivel
18 15018000 52 Ball Bearings 0.187 Dia S/S
19 10350007 1 2.5 O/BG Adapter
20 57297000 1 O-ring 1.612 ID x 0.103 C/S
21 59185007 1 Gallonage Ring
22 63678000 3 Set Screw #10-24 x 0.250 lg S/S
23 63418001 1 Stem (Web) Base
24 17196007 1 Nozzle Body
