Page 7
7
Power converts to 24
VDC in control panel
III SPECIFICATIONS
General Specs
Input Power
120/240 VAC (50/60Hz.) 1 Phase
480 VAC (50/60 Hz.) 3 Phase
500 VA max. Power
Electrical Load
4 AMPS MAX
Panel Dimensions
24” X 36” (609.60mm X 914.40mm)
Panel Weight
Approx. 100 lbs
Operating Temperature Range -10
o
C to +70
o
C
ATEX Product Marking
II 3 G c
Ex nA nC II T3
IV OPERATING INSTRUCTIONS
This control panel has one ON/OFF 2-position selector switch. Move it to the ON position so the pilot light
illuminates, showing the panel is now powered up, and ready for associated monitor operation.
V MAINTENANCE
Monthly Inspection and Maintenance
1. Check the indicator light and replace bulb if it’s not operable.
2. Confirm that all terminal blocks and connections are properly taut to 4.5 – 7.1 in-lbs. (0.508 – 0.802
Nm).
3. Check for proper operation of the system overall, if there are problems with the system please refer to
the Troubleshooting section for help.
