 P/N 36833100 (used since 2007) can be identified by the grey 3 pin Deutsch
connectors for attachment to the sensors. The 10 pin Packard connector is
located close to the monitor inlet.
o P/N 36833100 is a direct replacement.
STEP 6b1, STEP 9, & STEP10b REPLACE MONITOR CONTROL MODULE
 P/N 81713000 (Item 3) can be used for both 12v & 24v systems and can be used
in place of all older models.
STEP 6b2 & STEP 8 REPLACE MODULE TO MONITOR EXTENSION HARNESS
This harness (Item 13) attaches between the monitor harness and the monitor control
module connects to the vertical and horizontal motors and sensors and the nozzle
motor.
 P/N 36791000 length is 30 feet.
 P/N 36791100 length is 1 foot.
 P/N 36791200 length is 5 feet.
