Typical All RF Install Guide:
Control Components & Accessories
2
4.
5.
6.
A. Follow mounting templates on page
30 of the instruction manual for hole
diameters and dimensions.
B. Drill holes for CAN network and
power cables for each components’
leads behind each component.
C. Mount components to panel using
10-24 x 1/2” screws. Use Loctite 242 or
equivalent.
D. Add a 1A (12VDC)* fuse between
red component lead and positive power
lead.
A. Connect entire CAN network together using 18-22 AWG. Ensure every component connected to the CAN network is connected in between 2 end components that
have CAN termination. Please refer to the BLUE, GREEN, and BLACK lines as the CAN wires below.
*.5A (24VDC)
- Joystick Controller - OEM Interface Module
A. Install valve into plumbing. Torque
adapter bolts to spec using torque specs
listed to the right .
7/32” dia.
unless noted
CAN
Network
Wires
18g
98326040 Rev. Rel
B. Add a 30A(12VDC)* fuse between
RED controller lead and positive power
lead. *15A(24VDC)
16g
Handheld Controller / Docking Station -
1 3
4 2
Tighten Adapter
Bolts using a
cross pattern
25-30 ft-lbs
Before continuing please follow the steps on page 14 of the Sidewinder EXM instruction manual outlining the
Monitor Configuration Tool.
Connect power and
attach battery pack to
Handheld controller.
RF Installation - The cable will run the
length of the RF Module when installed
correctly.
