3. 8294-04 RELAY CONTROL BOX 81480001 (HORIZONTAL STOW POSITION, CENTER ):
a. STANDARD: The stowed position from the factory is with the monitor discharge
stopped at its upper travel limit and the monitor centered within the set horizontal
travel limits.
b. NOTE - (See instructions for setting the OPTIONAL stowed position with the
monitor discharge stopped at its lower travel limit and the monitor centered
within the set horizontal travel limits.)
4. 8294-04 RELAY CONTROL BOX 81480011 (HORIZONTAL STOW POSITION, LEFT ):
a. STANDARD: The stowed position from the factory is with the monitor discharge
stopped at its lower travel limit and the monitor rotated to the left horizontal
travel limit.
b. NOTE - (See instructions for setting the OPTIONAL stowed position with the
monitor discharge stopped at its upper travel limit and the monitor rotated to the
left horizontal travel limit.)
5. 8294-04 RELAY CONTROL BOX 81480021 (HORIZONTAL STOW POSITION, RIGHT ):
a. STANDARD: The stowed position from the factory is with the monitor discharge
stopped at its lower travel limit and the monitor rotated to the right horizontal
travel limit.
b. NOTE - (See instructions for setting the OPTIONAL stowed position with the
monitor discharge stopped at its upper travel limit and the monitor rotated to the
right horizontal travel limit.)
6. 8394-04 RELAY CONTROL BOX 81480101 (HORIZONTAL STOW POSITION, CENTER ):
a. STANDARD: The stowed position from the factory is with the monitor discharge
stopped at its lower travel limit and the monitor centered within the set horizontal
travel limits.
b. NOTE - (See instructions for setting the OPTIONAL stowed position with the
monitor discharge stopped at its upper travel limit and the monitor centered
within the set horizontal travel limits.)
3
