Page 6
can be conveniently placed on hose just behind the inlet connection for added monitor
support.
5) If it becomes necessary to move the monitor to a new location. Slowly close
the valve control handle and verify that the lock pin is latched. The monitor can
now be repositioned while the hose line is charged.
6) If the RAM is repositioned, verify that the criteria outlined in the “Deployment
of the RAM section” have been satisfied.
7) When use of the RAM is complete. Slowly close the valve control handle and
verify that the lock pin is latched.
8) Indicate to the pump operator to close the water feed to the hose line that is
attached to the RAM. Any residual hose line pressure can be released by slowly
opening and re-closing the valve control handle.
Storage of the RAM
The following steps outline the proper procedure for returning the RAM to
storage.
1) Remove the safety strap from the fixed object it had been secured to and place
the strap back into the attached pouch.
2) Fold the legs of the RAM by pulling outward on the lock pin cross lever to
disengage it. The front legs are folded towards the back first and the rear legs
are then folded forward.
3) If the RAM is not to be stored in a pre-connect condition, disconnect the hose
line from the monitor inlet.
4) Return the RAM to its mounting bracket or storage area and secure for
transportation.
Section 4 – Maintenance of the RAM
The following section outlines the necessary maintenance procedures for the RAM.
Adherence to these recommendations will keep the RAM operational and reduce the
possibility of field difficulty or failure.
Maintenance After Each Use
Verify that the carbide tipped ground spike on each of the four legs is sharp and
undamaged. If any tip has a flat larger than 1/16”, replace the carbide tip. If any
of the tips show signs of damage, replace the carbide tip ground spike before the
next use.
Verify that the lock pin mechanism for each leg is in good condition. Examine
the lock pin end and the leg bracket slot that the lock pin connects for damage. If
any damage is noticed, replace that specific leg assembly / bracket as needed.
Examine the spring to insure it is operating properly. If any springs are not
