dB TECHNOLOGIES OPERA 915 DX - Manual (Page 8)

OPERA 910 DX | OPERA 912 DX | OPERA 915 DX
Extraordinary Sound
DX
DX 912 DX 915
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 55 - 20.000 Hz
Frequency Response [+/- 3dB]: 68 - 19.000 Hz
Max SPL: 130 dB
HF: 1 “
Type HF: Compression driver
Directivity: 80/65 x 60 °
Horn: Asymmetrical CD Horn
LF: 12 “
Amplifier
Amp Technology: digipro®G2
Amp Class: Class D
Power PRG: 900 Wat
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 432 mm (17.28 in)
Height: 655 mm (26.2 in)
Depth: 353 mm (14.12 in)
Weight: 18,1 kg (39.68 lbs)
OPERA 912 DX
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 48 - 20.000 Hz
Frequency Response [+/- 3dB]: 58 - 19.000 Hz
Max SPL: 131 dB
HF: 1 “
Type HF: Compression driver
Directivity: 80/65 x 60 °
Horn: Asymmetrical CD Horn
LF: 15 “
Amplifier
Amp Technology: digipro®G2
Amp Class: Class D
Power PRG: 900 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 432 mm (17.28 in)
Height: 655 mm (26.2 in)
Depth: 353 mm (14.12 in)
Weight: 18,8 kg (39.68 lbs)
OPERA 915 DX
Professional Active Speakers
59
