dB TECHNOLOGIES OPERA 915 DX - Manual (Page 7)

OPERA 910 DX | OPERA 912 DX | OPERA 915 DX
Professional Active Speakers
OPERA DX 900
High-end Audio Performance
It doesn’t get any better than this: The OPERA 900 is not only the flagship
of the line, it is also the reference standard for the entire class.
Its 900-watt digipro®G2 power amp comes with a SMPS and an onboard
DSP. Paired with a premium woofer and a high-end driver sporting a
1.4“ diaphragm, it packs a powerful low-frequency punch and comjures
crystal-clear top end. Its range is nothing short of remarkable.
900
DX 910
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 60 - 20.000 Hz
Frequency Response [+/- 3dB]: 68 - 19.000 Hz
Max SPL: 129 dB
HF: 1 “
Type HF: Compression driver
Directivity: 80/65 x 60 °
Horn: Asymmetrical CD Horn
LF: 10 “
Amplifier
Amp Technology: digipro®G2
Amp Class: Class D
Power PRG: 900 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 343 mm (13.72 in)
Height: 553 mm (22.12 in)
Depth: 304 mm (12.16 in)
Weight: 11,7 kg (24.25 lbs)
OPERA 910 DX
58
DX
DX
