dB TECHNOLOGIES OPERA 915 DX - Manual (Page 4)

OPERA 508DX | OPERA 510DX | OPERA 512DX | OPERA 515DX
Extraordinary Sound
DX
DX 512 DX 515
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 59 - 20.000 Hz
Frequency Response [+/- 3dB]: 70 - 19.000 Hz
Max SPL: 126 dB
HF: 1 “
Type HF: Compression driver
Directivity: 80/65 x 60 °
Horn: Asymmetrical CD Horn
LF: 12 “
Amplifier
Amp Technology: digipro®
Amp Class: Class D
Power PRG: 400 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 432 mm (17.28 in)
Height: 655 mm (26.2 in)
Depth: 353 mm (14.12 in)
Weight: 15,8 kg (33.07 lbs)
OPERA 512 DX
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 52 - 20.000 Hz
Frequency Response [+/- 3dB]: 60 - 19.000 Hz
Max SPL: 127 dB
HF: 1 “
Type HF: Compression driver
Directivity: 80/65 x 60 °
Horn: Asymmetrical CD Horn
LF: 15 “
Amplifier
Amp Technology: digipro®
Amp Class: Class D
Power PRG: 400 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 432 mm (17.28 in)
Height: 655 mm (26.2 in)
Depth: 353 mm (14.12 in)
Weight: 16,7 kg (35.27 lbs)
OPERA 515 DX
Professional Active Speakers
55
