dB TECHNOLOGIES OPERA 915 DX - Manual (Page 3)

OPERA 508DX | OPERA 510DX | OPERA 512DX | OPERA 515DX
Professional Active Speakers
500
DX
DX 508 DX 510
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 67 - 20.000 Hz
Frequency Response [+/- 3dB]: 78 - 19.000 Hz
Max SPL: 121 dB
HF: 1 “
Type HF: Compression driver
Directivity: 80/65 x 60 °
Horn: Asymmetrical CD Horn
LF: 8 “
Amplifier
Amp Technology: digipro®
Amp Class: Class D
Power PRG: 400 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 300 mm (12 in)
Height: 484 mm (19.36 in)
Depth: 284 mm (11.36 in)
Weight: 7,9 kg (15.43 lbs)
OPERA 508 DX
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 62 - 20.000 Hz
Frequency Response [+/- 3dB]: 71 - 19.000 Hz
Max SPL: 122 dB
HF: 1 “
Type HF: Compression driver
Directivity: 80/65 x 60 °
Horn: Asymmetrical CD Horn
LF: 10 “
Amplifier
Amp Technology: digipro®
Amp Class: Class D
Power PRG: 400 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 343 mm (13.72 in)
Height: 553 mm (22.12 in)
Depth: 304 mm (12.16 in)
Weight: 9.8 kg (21.61 lb)
OPERA 510 DX
54
DX
