DRK-20M
Motorized Rigging Frame
21
DRK-20M
Motorized Rigging Frame
The New DRK-20M
The new DRK-20 M is also equipped with an RD_NET interface, in order
to control each of its functions through a computer and monitor its
position in real time.
The new motorized Fly bar is also very useful in facilitating the
installation of line array modules by adjusting the clusters inclination
progressively, as each single modules’ applied angles vary.
Thanks to its solid structure in special steel, it is possible to hang
speakers of the DVA series with a weight of up to 1000kg, TUV
certified.
0°
Remote Control
Manual Mode
RDNet Control Mode (Plug in)
RDNet Connections
Remote Control
Connectioncs
Remote Control
DRK20M
0°
Auto
Active Data Input Data Link
Link
Data Input
PUSH PUSH
Remote Control Data Service
USB
Power
On
Remote Control Data Service Power
UP+DOWN = GO TO ZERO
2 1 3
UP
DOWN
PUSH
